Product Details:
|
| Material: | SUS Steel | Application: | Large Sum Plastic Materials |
|---|---|---|---|
| Loading Method: | Motor Running With Screw | Distance: | Less Than 5 M |
| Voltage: | 380V/50Hz/3Phase As Usual | Power(w): | 1.5kw |
| Condition: | New | Warranty: | 12 Months |
| Highlight: | Screw Hopper Feeder Conveyor,Plastic Hopper Feeder Conveyor |
||
OSF Screw Feeder for Plastic Recycled Material.pdf...
OSF-xx-x
① ② ③
① Orste Screw Feeder
② Outer Dia.of Conveying Pipe (mm)
③ Length of Conveying Pipe (m)
Evenly mix different materials and effectively avoid material stratification during conveying process
Motor-driven screw ensures low noise level in operation
Fully closed conveying line, effectively avoid material contamination in the conveying process
Stainless steel made screw, easy for installation and maintenance
Reverse phase protector is pre-installed to avoid that the motor is incapable of conveying materials because of motor reversal
The length of conveying pipeline can be determined by customer’s needs
The screw feeder is mainly used with extruders of various specifications to automatically convey plastic materials from storage tank to the hopper. It achieves the automatic feeding through the circulation controlled by material level sensor. It features stable function, labor saving, safe and reliable.
|
Model |
Motor Power (kw) |
Conveying Capacity (kg/hr) |
Pipe Diameter (mm) |
Vertical Conveying Height (m) |
Pipe Length (mm) |
Inclining Angle (o) |
Weight (kg) |
|
OSF-14-3 |
3 |
1000 |
141 |
1.8 |
3 |
45 |
180 |
|
OSF-14-3 |
4 |
1000 |
141 |
2.3 |
195 |
||
|
OSF-16-3 |
5.5 |
1500 |
159 |
3 |
210 |
We reserve the right to change parameters without prior notice.
Notes:
(1) Conveying capacity is based on pellet material of 0.65kg/L in bulk density and 3-5mm in diameter.
(2) Special requirements for “OSF” can be customized.
(3) Power: 3ф, 230/400/460/575VAC, 50/60Hz.
FAQ
Q1: What kind of company are you? Trading company or manufacturer?
A: We are a manufacturing company with more than 12 years design and manufacturing experience in Dongguan, Guangdong Province, China.
Q2: How long is the delivery time?
A: 7-30 days after order confirmed. Based on the actual requirement.
Q3: What's the MOQ?
A: 1 set per order.
Q4: What is your terms of payment?
A: For order amount ≤ 2000 USD, 100% in advance; For order amount ≥ 2000 USD, T/T 50% as order, balance 50% T/T before shipping. We will show you the pictures and videos of the machines for the order.
Q5: What are the trading terms?
A: EXW, FOB and CIF.
Q6: Can you do OEM?
A: Yes, OEM and ODM service are provided.
Q7: Do you test all your machines before packing and delivery?
A: Yes, we haved tested all our machines well before delivery.
Q8: How to provide the after-sales service?
A: 1st, our machines are manufactured in strict quality control system to make sure there is few faulties occur after installation, but if any faulty, we can send new spare parts for free in 12 months warranty time.
2nd, our technician will periodically follow up customer to help to do maintenance and ensure equipment operation 7/24 be guaranteed.
3rd, we have over 30 3rd-party cooperation agents or service centers around the world to proivde in-time after-sales service for the customers nearby.
Q9: How can get the shipping cost?
A: We can calculate the shipping cost for you if you provide us your destination port.
