Product Details:
|
| Material: | Stainless Steel & Aluminum | Application: | Plastic Drying & Loading |
|---|---|---|---|
| Color: | Gray & Green | Origin: | China |
| Condition: | New | Warranty: | 12 Months |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Overseas Third-party Support Available,No Overseas Service Provided,Overseas Service Center Available | Capacity: | 12kg~1000kg |
| Highlight: | Compact Drying Hopper Loader,CE Drying Hopper Loader,Plastic Compact Hopper Dryer |
||
ODL Drying Loader Drying Hopper.pdf
Drying Loader, Hopper Loader, Plastic Drying Loader, Compact Dryers, Plastic Loading Dryers
ODL – xxx – xxx
① ② ③
① Orste Drying Loader
② Hopper Capacity (L)
③ Loader Model
Material-contact surface made of stainless steel to eliminate material contamination.
The closely casting aluminum shell ensures excellent insulation.
Hot air inlet elbow design can effectively avoid burning caused by dust piling up at the bottom of the pipe heaters.
The hopper design is convenient for cleaning and material change.
Accurate temperature controller guarantees easy control of temperature.
Overheat protection device makes machine run safely and reliably.
Dust-proof mute blower prevents dust from polluting material.
Material window in hopper and base makes it convenient to observe the material usage.
The plastic resin is loaded by the vacuum loader to the drying hopper, after drying, the dried resin is loaded to the feeding port of the molding machine. It's suitable for normal plastic resin drying, not suitable for hygroscopic resin drying. For drying of hygroscopic plastic granules, low dew-point dehumidifying dryers are needed for drying.
|
Model |
Applicable Dryer |
Applicable Loader |
Vacuum Hopper Receiver |
Conveying Capacity (kg/hr) |
Hopper Capacity (L) |
Measurement (mm) |
Weight (kg) |
|
|
ODL-40 |
OHD-40 |
OAL-1.5S |
OAL-1S |
1 x OMH-7.5L |
300 |
1*7.5 |
620*1000*640 |
95 |
|
OAL-2S |
1 x OPH-7.5L 1 x OMH-7.5L |
450 |
2*7.5 |
|||||
|
ODL-80 |
OHD-80 |
OAL-1.5S |
OAL-1S |
1 x OMH-7.5L |
300 |
1*7.5 |
750*1000*640 |
110 |
|
OAL-2S |
1 x OPH-7.5L 1 x OMH-7.5L |
450 |
2*7.5 |
|||||
|
ODL-120 |
OHD-120 |
OAL-1.5S |
OAL-1S |
1 x OMH-7.5L |
300 |
1*7.5 |
850*1000*640 |
115 |
|
OAL-2S |
1 x OPH-7.5L 1 x OMH-7.5L |
450 |
2*7.5 |
|||||
|
ODL-160 |
OHD-160 |
OAL-1.5S |
OAL-1S |
1 x OMH-7.5L |
300 |
1*7.5 |
950*1080*710 |
155 |
|
OAL-2S |
1 x OPH-7.5L 1 x OMH-7.5L |
450 |
2*7.5 |
|||||
|
ODL-300 |
OHD-300 |
OAL-1S |
1 x OMH-7.5L |
300 |
1*7.5 |
2000*1080*710 |
160 |
|
|
OAL-2S |
1 x OPH-7.5L 1 x OMH-7.5L |
450 |
2*7.5 |
|||||
|
ODL-600 |
OHD-600 |
OAL-2S |
1 x OMH-7.5L |
400 |
12 |
3850*1140*840 |
210 |
|
|
OAL-3S |
1 x OPH-7.5L 1 x OMH-7.5L |
700 |
2*12 |
|||||
