Dehumidifying Machine 3-In-1 Compact Dryer OCD-80/80H For Auto Plastic Parts

NAMING PRINCIPLE of Dehumidifying Hopper Dryer

OCD – xx/xxxH

①        ②  ③

① Orste “Three-in-one” Compact Dryer

② Hopper Capacity (L)

③ Dehumidifying Air Quantity (m³/hr)

H: Honeycomb Rotor Type

Product Features of Dehumidifying Hopper Dryer

1.       The OCD compact dryers can be equipped with up to four fully insulated drying bins to suit the required total throughput.

2.       OCD compact dryers are the most effective way of conditioning hygroscopic plastic granules for processing and removing surface moisture.

3.       The use of corrosion resistant stainless steel ensures a long lifetime and avoids contamination of the plastic granules.

4.       Transparent window design for filter makes it convenient to monitor the condition of filter.

5.       Material-contact surface of hopper is specially made of dust-free mirror-like stainless steel, it is suitable for the production of optical lens or food standard plastic products production.

6.       High-density return air filter ensures no contamination to the material in the conveying of materials.

7.       For models below OCD-160/120H, air-cooling methods is applied, which ensures low energy-saving and convenient for movement.

Application of Dehumidifying Hopper Dryer

ORSTE “Optical” Dehumidifying Dryers provides the advantages of a consistent dew point and maximum energy efficiency. They combine the function of dehumidifying, drying and two-stage conveying into one compact machine, specified for the production of “optical class” and “food standard” products, such as lens, LGP, disposable lunch box etc. The quality desiccant honeycomb rotor provides continuous and constant low dew-point air which can be lower than -40 ^oC under ideal conditions.

Product Specification / Parameters of Dehumidifying Hopper Dryer

Product Details of Dehumidifying Hopper Dryer

The above part is a dust collector, it is an important part for the machine if there is much dust in the plastic materials. It can remove most of the dust like substance in the plastic and greatly improve the service lifespan of the machine.

The above part is an oil removing device. If the plastic material contains some oil-like substance, the oil-like substance can go back to the honeycomb rotor which can block the holes in it. Then the drying effect and performance of the machine will be reduced a lot. So in this circumtance, the oil removing device is needed.

Matters Needing Attention

Electrical installation of the machine should be done by qualified electricians.

Before connecting to AC Power Source, turn power switch to OFF position. While AC power source is connected, make sure specifications and overload protection rating of the power switch are suitable and reliable. When the machine is under care or maintenance, turn off both power switch and automatic operation switch.

Dehumidifying Dryers are designed to eliminate moisture in the plastic material before processing. Air is forced through a desiccant bed to make it extremely dry. This air is then heated to a specified temperature and fed into a Drying Hopper containing the material to be dried. This hot dry air draws the moisture out of the material; the saturated air is then fed out of the Drying Hopper and back through the desiccant bed again to remove the moisture before the cycle begins again. This desiccant has a limited ability to hold moisture before it needs to be regenerated (dried out). Typically, plastics processors use regenerative or twin tower dryers and in this case, when the desiccant bed has reached its moisture retaining capacity the airflow is automatically switched to the second desiccant bed to allow the drying process to continue. At the same time, the first desiccant bed is regenerated by heating to remove moisture, allowed to cool and it is then ready to absorb moisture again.
