Product Details:
|
Application: | Drying Of Hygroscopic Plastic Material | Color: | Blue & White |
---|---|---|---|
Method: | Air Drying | Hopper Material: | Corrosion Resistant Stainless Steel |
Weight: | Different As Different Specifications | Name: | Industrial Plastic Pellet Hopper Dryer In China |
Usage: | Plastic Industry(dehumidifying Dryer) | Hopper Capacity: | 100kg |
Highlight: | Industrial Plastic Dehumidifying Dryer,CE Plastic Dehumidifying Dryer,Industrial Desiccant Dryers For Plastics |
OCD – xx/xxxH
① ② ③
① Orste “Three-in-one” Compact Dryer
② Hopper Capacity (L)
③ Dehumidifying Air Quantity (m3/hr)
H: Honeycomb Rotor Type
Product Features of Dehumidification Dryer
ORSTE “Optical” Dehumidifying Dryers provides the advantages of a consistent dew point and maximum energy efficiency. They combine the function of dehumidifying, drying and two-stage conveying into one compact machine, specified for the production of “optical class” and “food standard” products, such as lens, LGP, disposable lunch box etc. The quality desiccant honeycomb rotor provides continuous and constant low dew-point air which can be lower than -40 oC under ideal conditions.
Product Specification / Parameters of Dehumidification Dryer
Model OCD- | 20/40H | 40/40H | 80/80H | 120/80H | 160/120H | 230/120H | 300/200H | 450/200H | 600/400H | 750/400H | |
Drying System | |||||||||||
Hopper Capacity (kg) | 12 | 25 | 50 | 75 | 100 | 150 | 200 | 300 | 400 | 500 | |
Drying Heating Power (kw) | 4 | 4 | 4 | 4 | 6 | 6 | 12 | 12 | 18 | 18 | |
Drying Blower Power (kw) | 0.4 | 0.4 | 0.7 | 0.7 | 0.7 | 0.7 | 1.5 | 1.5 | 3.75 | 3.75 | |
Dehumidifying System | |||||||||||
Dehumidifying Air Quantity (m3/hr) | 40 | 40 | 80 | 80 | 120 | 120 | 200 | 200 | 400 | 400 | |
Regenerative Heater Power (kw) | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 5.4 | 5.4 | 7.2 | 7.2 | |
Regenerative Blower Power (kw) | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.4 | 0.4 | 0.75 | 0.75 | |
Feeding System | |||||||||||
Feeding Blower Power(kw) | 0.75 | 0.75 | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | 1.5 | 2.2 | 2.2 | |
Dia. of Material Pipe (inch) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
Dia. of Return Air Pipe (inch) | 2 | 2 | 2 | 2 | 2.5 | 2.5 | 2.5 | 2.5 | 3 | 3 | |
OMH (L) | 7.5 | 7.5 | 7.5 | 7.5 | 7.5 | 12 | 12 | 12 | 12 | 30 | |
OPH (L) | 3 | 3 | 3 | 3 | 3 | 7.5 | 7.5 | 7.5 | 12 | 12 | |
Dimension | H (mm) | 1490 | 1870 | 2010 | 2100 | 2260 | 2370 | 2370 | 2410 | 2520 | 2570 |
W (mm) | 1000 | 1050 | 1180 | 1180 | 1340 | 1340 | 1440 | 1460 | 1645 | 1645 | |
D (mm) | 730 | 730 | 780 | 780 | 810 | 810 | 940 | 940 | 1145 | 1145 | |
Weight (kg) | 280 | 295 | 325 | 340 | 505 | 515 | 570 | 610 | 650 | 700 |
Filter Cleaning
Please periodically clean the dust on the air filters, once per week.
Cleaning steps:
1) Take out the air filter carefully.
2) Blow off the dust on the air filter screen and the cover with pressure air.
3) Wipe off the barrel wall of air filter with dishcloth.
4) After cleaning, place all parts in reversed order carefully.
Note!
Do not let any impurities fall into filter container.
Why Choose OCD-H?
The main reason for the defects of plastic products, such as bubbles, silver lines, flaws, poor transparency, etc. is that plastic raw materials are not completely dried before molding. Hygroscopic plastics, such as TPU, PA, PC, PBT, PET, PETG, PCTG, NYLON and so on, can not be thoroughly dried through traditional methods. It is proved that heated and dehumidified air with low dew-point down to -40oC can make moisture content of such materials lower than 0.02% before molding.
OCD-H honeycomb dehumidifiers, utilizing honeycomb-rotor in a full-closed system to dehumidify process air, can meet such requirements. Hot air with low dew-point produced by this unit is quickly and continuously blowed to plastic particles to completely absorb the moisture, thus to gain a good drying and dehumidifying effect.
