Product Details:
|
| Material: | SUS Steel | Application: | Plastic Sprues |
|---|---|---|---|
| Motor: | Slow Speed Type | Capacity: | 20 Kg/H |
| Volume: | Compact | Voltage: | 3 Phase / 380 V / 50Hz |
| Warranty: | 24 Months | Delivery: | 15 Days For Standard Models |
| Highlight: | 1.5KW 20 Kg/H Low Speed Plastic Granulator,20 Kg/H Low Speed Plastic Granulator,White 20 Kg/H Low Speed Plastic Granulator |
||
OG-LS Low-speed Granulator Granulating Machine.pdf...
1. For OG- series granulators, teeth cutter and cutting blades are integrally fitted in one cutting chamber. Regrinds could be used with virgin materials.
2. New-type inclined teeth cutter reduces the possibility of stress concentration, enhance bearing capacity and converts force direction so that cutter lifespan can be prolonged.
3. The material collector is located outside the cutting chamber to avoid leakage.
4. Optimum cutting angle makes resistance small and avoid blockage to improve cutting efficiency.
5. Optimal design can effectively reduce vibration during operation of granulator.
6. Cutting chamber is made of mirror finished stainless steel, which is durable and elegant.
7. Low speed granulating ensures well-proportioned granules and low dust level.
8. Low speed and sound-proof material hopper brings a quiet operation environment.
9. Easy access to maintenance and cleaning.
10. Small in size with castors for easy moving.
OG series granulators are applied to granulate sprues or few defects. They are always collocated with robots or belt conveyors beside the injection moulding machine. They feature low speed, big driving torque, low noise, few dust and easy operation.
| Model | Motor Power | Hopper Size (mm) | Qty. of Staggered Cutter | Qty. of Teeth Cutter | Rotating Speed (rpm) | Max. Capacity (kg/hr) | Dimension L*W*H (mm) | Weight (kg) | |
| kw | hp | ||||||||
| OG-1217-1LS | 0.75 | 1 | 230*165 | 1 | 2 | 27~35 | 15 | 540*320*880 | 165 |
| OG-2326-2LS | 1.5 | 2 | 230*255 | 2 | 3 | 27~35 | 20 | 540*400*900 | 200 |
| OG-2626-3LS | 2.2 | 3 | 260*261 | 2 | 3 | 27~35 | 20 | 540*400*900 | 220 |
| OG-2636-3LS | 2.2 | 3 | 260*360 | 3 | 4 | 27~35 | 25 | 610*500*920 | 250 |
| OG-2636-5LS | 3.75 | 5 | 260*360 | 3 | 4 | 27~35 | 25 | 610*500*920 | 270 |
| OG-3136-5LS | 3.75 | 5 | 310*360 | 3 | 4 | 27~35 | 30 | 610*500*920 | 300 |
With many years of experience and accumulation in scientific researching and designing of our five series products: Dehumidifying and Drying, Feeding and Conveying, Dosing and Mixing, Heating and Cooling, Granulating and Recycling, and upholding the principle of “Focusing on Product Details, Pursuing Excellent Quality”, “Perfect Product Comes From Endless Innovation”.
ORSTE spares no efforts to innovate its technology while improving product quality, and now it is an industry leader with its mature technology, professional research and development ability, quick marketing capability and qualified site construction team in peripheral equipment of plastic molding.
FAQ
Q1: What kind of company are you? Trading company or manufacturer?
A: We are a manufacturing company with more than 12 years design and manufacturing experience in Dongguan, Guangdong Province, China.
Q2: How long is the delivery time?
A: 7-30 days after order confirmed. Based on the actual requirement.
Q3: What's the MOQ?
A: 1 set per order.
Q4: What is your terms of payment?
A: For order amount ≤ 2000 USD, 100% in advance; For order amount ≥ 2000 USD, T/T 50% as order, balance 50% T/T before shipping. We will show you the pictures and videos of the machines for the order.
Q5: What are the trading terms?
A: EXW, FOB and CIF.
Q6: Can you do OEM?
A: Yes, OEM and ODM service are provided.
Q7: Do you test all your machines before packing and delivery?
A: Yes, we haved tested all our machines well before delivery.
Q8: How to provide the after-sales service?
A: 1st, our machines are manufactured in strict quality control system to make sure there is few faulties occur after installation, but if any faulty, we can send new spare parts for free in 12 months warranty time.
2nd, our technician will periodically follow up customer to help to do maintenance and ensure equipment operation 7/24 be guaranteed.
3rd, we have over 30 3rd-party cooperation agents or service centers around the world to proivde in-time after-sales service for the customers nearby.
Q9: How can get the shipping cost?
A: We can calculate the shipping cost for you if you provide us your destination port.
