Product Details:
|
| Color: | White & Blue | Material: | Stainless Steel |
|---|---|---|---|
| Drying Method: | Hot Air | Feature: | For Small Quantity Plastic Material Drying |
| Voltage: | 380v3phase | Power(w): | 6.4kw |
| Condition: | New | Weight: | 180kg |
| High Light: | 6.4KW Drying Industrial Oven,Plastic Granules Drying Industrial Oven,Plastic Resin Cabinet Tray Dryer |
||
OOD Oven Dryer Cabinet Dryer.pdf
Plastic Dryer, Plastic Drying Machine, Plastic Equipment, Oven Dryer, Cabinet Dryer; Tray Dryer
OOD - xxx
① ②
① Orste Oven Dryer
② Quantity of Trays
1. Accurate P.I.D temperature controller to achieve even drying effect.
2. Air-proofed insulated door can effectively avoid heat loss to reduce energy consumption
3. Stainless steel tray and liner bring no contamination to materials. OOD series can dry several materials at the same time, time-saving and efficient.
4. 24 hours timer which is easy to operate to preset the drying time.
5. Multilevel protection measures like overheat protector and alarm light can reduce mechanical and human error accidents.
6. Adjustable air inlet and outlet design, air volume can be adjusted according to customer’s actual needs.
OOD series of oven dryers are mostly used for simultaneous drying of different kinds of polymers in small quantities or for drying materials for trial molding. For tempering after plastic molding, it can increase product tenacity and improve product quality. The oven dryer can also be applied in preheating and drying of agricultural and food (grain, garlic, tea, and etc.), electric motor and part, electroplating, pharmaceutical, paint, printing and others.
|
Model |
OOD-5 |
OOD-9 |
OOD-20 |
|
External dimension L*W*H (mm) |
820×630×1260 |
820×630×1480 |
820×1500×1750 |
|
Internal dimension L*W*H (mm) |
500×600×600 |
500×600×900 |
500×1150×1200 |
|
Motor Power(kw) |
0.375 |
0.375 |
1.5 |
|
Heater (kw) |
4.5 |
6 |
6*2 |
|
No. of Trays |
5 |
9 |
20 |
|
Tray Dimensions L*W*H (mm) |
600×500×50 |
600×500×50 |
600×500×50 |
|
Capacity (kg) |
50 |
90 |
200 |
|
Material |
SUS304 stainless steel plate |
||
|
Temperature range |
40oC ～180oC |
||
|
Accuracy |
±5% |
||
|
Weight (kg) |
148 |
178 |
415 |
| Fault | Possible Reasons | Solution |
| It doesn’t start after turning on the main switch | The motor switch isn't open. | Turn on the motor switch. |
| The fuse is broken | 2. Replace a new fuse. | |
| The transformer is burnt out. | 3. Replace a new transformer. | |
| The motor doesn’t run. | 1. The motor switch isn’t open. | 1. Turn on the motor switch. |
| 2. The circuit breaker trips. | 2. Press “RESET” key. | |
| 3. The magnet contactor breakdowns. | 3. Replace a new magnet contactor. | |
| 4. The motor is burned out. | 4. Replace a new motor. | |
| The temperature is abnormal | 1. The temperature controller breakdowns. | 1. Replace it. |
| 2. The temperature contactor breakdowns. | 2. Replace it. | |
| 3. The magnet contactor breakdowns. | 3. Replace it. | |
| 4. The heater breakdowns. | 4. Replace it. |
