Product Details:
|
| Application: | Plastic Processing | Structure: | Compact |
|---|---|---|---|
| Function: | Dehumidifying Drying | Drying Method: | Hot Dry Air |
| Condition: | New | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Capacity: | Different As Different Specifications | Dimension: | Different As Different Specifications |
| High Light: | Dehumidifying Hot Air Dryer For Plastic,Honeycomb Hot Air Dryer For Plastic,Desiccant Dehumidification Dryer |
||
OCD – xx/xxxH
① ② ③
①Orste “Three-in-one” Compact Dryer
②Hopper Capacity (L)
③Dehumidifying Air Quantity (m3/hr)
H: Honeycomb Rotor Type
1. The OCD compact dryers can be equipped with up to four fully insulated drying bins to suit the required total throughput.
2. OCD compact dryers are the most effective way of conditioning hygroscopic plastic granules for processing and removing surface moisture.
3. The use of corrosion resistant stainless steel ensures a long lifetime and avoids contamination of the plastic granules.
4. Transparent window design for filter makes it convenient to monitor the condition of filter.
5. Material-contact surface of hopper is specially made of dust-free mirror-like stainless steel, it is suitable for the production of optical lens or food standard plastic products production.
6. High-density return air filter ensures no contamination to the material in the conveying of materials.
ORSTE “Optical” Dehumidifying Dryers provides the advantages of a consistent dew point and maximum energy efficiency. They combine the function of dehumidifying, drying and two-stage conveying into one compact machine, specified for the production of “optical class” and “food standard” products, such as lens, LGP, disposable lunch box etc. The quality desiccant honeycomb rotor provides continuous and constant low dew-point air which can be lower than -40 oC under ideal conditions.
|
Model OCD- |
20/40H |
40/40H |
80/80H |
120/80H |
160/120H |
230/120H |
300/200H |
450/200H |
600/400H |
750/400H |
|
|
Drying System |
|||||||||||
|
Hopper Capacity (kg) |
12 |
25 |
50 |
75 |
100 |
150 |
200 |
300 |
400 |
500 |
|
|
Drying Heating Power (kw) |
4 |
4 |
4 |
4 |
6 |
6 |
12 |
12 |
18 |
18 |
|
|
Drying Blower Power (kw) |
0.4 |
0.4 |
0.7 |
0.7 |
0.7 |
0.7 |
1.5 |
1.5 |
3.75 |
3.75 |
|
|
Dehumidifying System |
|||||||||||
|
Dehumidifying Air Quantity (m3/hr) |
40 |
40 |
80 |
80 |
120 |
120 |
200 |
200 |
400 |
400 |
|
|
Regenerative Heater Power (kw) |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
5.4 |
5.4 |
7.2 |
7.2 |
|
|
Regenerative Blower Power (kw) |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
0.4 |
0.4 |
0.75 |
0.75 |
|
|
Feeding System |
|||||||||||
|
Feeding Blower Power(kw) |
0.75 |
0.75 |
1.1 |
1.1 |
1.1 |
1.1 |
1.5 |
1.5 |
2.2 |
2.2 |
|
|
Dia. of Material Pipe (inch) |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
|
|
Dia. of Return Air Pipe (inch) |
2 |
2 |
2 |
2 |
2.5 |
2.5 |
2.5 |
2.5 |
3 |
3 |
|
|
OMH (L) |
7.5 |
7.5 |
7.5 |
7.5 |
7.5 |
12 |
12 |
12 |
12 |
30 |
|
|
OPH (L) |
3 |
3 |
3 |
3 |
3 |
7.5 |
7.5 |
7.5 |
12 |
12 |
|
|
Dimension |
H (mm) |
1490 |
1870 |
2010 |
2100 |
2260 |
2370 |
2370 |
2410 |
2520 |
2570 |
|
W (mm) |
1000 |
1050 |
1180 |
1180 |
1340 |
1340 |
1440 |
1460 |
1645 |
1645 |
|
|
D (mm) |
730 |
730 |
780 |
780 |
810 |
810 |
940 |
940 |
1145 |
1145 |
|
|
Weight (kg) |
280 |
295 |
325 |
340 |
505 |
515 |
570 |
610 |
650 |
700 |
|
Electrical installation of the machine should be done by qualified electricians.
Connecting the cooling water (if needed) after the machine is installed in a appointing place, make sure the inlet and outlet water pipe is in good condition.
Before connecting to AC Power Source, turn power switch to OFF position. While AC power source is connected, make sure specifications and overload protection rating of the power switch are suitable and reliable. When the machine is under care or maintenance, turn off both power switch and automatic operation switch.
