Plastic Injection Mold Temperature Controller Water Heating Unit​

OMT-W Mold Temperature Controller Water Heater.pdf...

Product Features of Temperature Control Unit for Injection Molding

• Equipped with the design of one week automatic start/stop timer, screen can be converted between Chinese and English.
• P. I. D. multi-stage temperature control system can maintain a mold temperature with an accuracy of ±1^oC.
• Adopts high efficiency water cycle pump, which can meet the demands of temperature control for precise molds and mold loop with minor diameter to achieve precise temperature control and high efficiency heat exchange. Pump inside adopts stainless steel to avoid explosion.
• Multiple safety devices including power reverse phase protection, pump overload protection, overheat protection and low level protection that can automatically detect abnormal performance and indicate this via visible alarm.
• For standard OMT-W, the heating temperature can reach 120^oC, while for OMT-HT, it can reach 160^oC.
• Equipped with high pressure protection, safety pressure relieving, automatic water supplying and air exhausting.
• For OMT-W, direct cooling is adopted. Automatic water supplying device ensures fast heat exchange.

Application of Temperature Control Unit for Injection Molding


OMT-W series water heaters are widely used in the production of plastic product. They are mainly applied to heat up the mold and maintain temperature, also they can be used in other similar fields. Through the principle of heat exchange, they can shorten the product mold cycle and improve production efficiency.


PARAMETERS of Temperature Control Unit for Injection Molding

Machine Details of Temperature Control Unit for Injection Molding

Notes for Installation and Positioning:

1) Machine just can be mounted in vertical position. Make sure there’s no pipe, fixed structure or other objects above the installing location and around the machine which may block machine’s installation, hit objects or injure human person.

2) In order to maintain convenient operation, it’s suggested to keep 1m space around the machine. Please keep at least 2m distance between the device and the inflammable goods.

3) This series of models only could be applied in working environment with good ventilation.
