Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80

Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80
Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80
Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80 Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80 Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80 Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80 Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80

Large Image :  Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80

Product Details:
Place of Origin: Dongguan, China
Brand Name: ORSTE
Certification: CE, ISO, SGS
Model Number: OST-80
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set / Order
Price: USD 198 / SET
Packaging Details: Standard Export Packing
Delivery Time: 7-15 days
Payment Terms: TT, LC, Paypal, West Union, Cash
Supply Ability: 500-3000 Sets / Year

Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80

Description
Material: Blank SUS Capacity: 80-1000L
Thickness: Wall Thickness From 1 To 2.5 Mm Application: Plastic Storing
Warranty: 36 Months Delivery: 10 Days For Standard Model
Name: Storage Silo For Plastic Feature: With Suction Box
Highlight:

Plastic Resin Silo Storage Tank

,

ISO Plastic Resin Silo Storage

,

Granules Plastic Storage Silos

Blank SUS Plastic Resin Pellet Silo Storage Bin Tank For Granules Storing OST-80

OST Technical Specification & Applications.pdf



Introduction of Pellet Storage Bin


ORSTE's plastic storage tank is used to store small quantity of plastic pellet before pre-drying of pre-processed. It makes the plastic plant looks elegant, tidy and clean. The standard model OST-80 can contain 80L / 50kg material. Other models can be customized according to customer's actual needs.



Product Feature of Pellet Storage Bin



  • Standard Model is made of SUS 201, for SUS 304 material, can be customized.
  • Models end with “O” means Optical, it’s specially surface treated, suitable for optical and food grade plastic products production.
  • Suction Box pipe Diameter is 38 mm (Standard), Can be customized according to customer’s actual need.
  • Unique humanisticly designed storage tank with compact structure, the height is lower than other similar product which enable easy dumping of resin manually.



Description of Pellet Storage Bin


When processing small quantities of engineering plastics, efficient and optimal storage of the material is crucial to ensure impeccable product quality. ORSTE's storage bin is made of mirror-like stainless steel, thus the process before pre-drying is without contamination.
With the OST-80 Storage Tank, ORSTE provides a cost-effective solution for the economical storage of all types of pre-dried plastic granules in 25 kg material bags. The tank is equipped with mobile frame (with castors) which ensures easy movement. It is made of stainless steel which ensures no contamination to the plastic materials.



Product Parameters of Pellet Storage Bin



Model Capacity (L / Kg) Dimension L*W*H (mm) Material Thickness (mm) Weight (kg)
OST-80 80 / 50 500*500*900 SUS 201 1.2 20
OST-80-O 80 / 50 Dia. 500 * H. 1180 SUS 201 1.2 21
OST-160 160 / 100 600*600*900 SUS 201 1.5 46
OST-300 300 / 200 806*806*858 SUS 201 1.5 60
OST-460 460 / 300 1206*1206*818 SUS 201 2.0 78
OST-800 800 / 500 1206*1206*1033 SUS 201 2.0 100
OST-2300 2300/1500 1290*1290*3035 SUS 201 3.0 470
OST-4500 4500/3000 2020*2020*3000 SUS 201 3.0 610
OST-8000 8000/5000 2180*2180*3800 SUS 201 4.0 820
OST-16000 16000/10000 2180*2180*6153 SUS 201 4.0 2000
OST-20000 20000/12500 2180*2180*7200 SUS 201 4.0 2350


We reserve the right to change parameters without prior notice.



Applications of Pellet Storage Bin



Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80 0



Storage Tanks are always applied in plastic injection molding to store the plastic resin temporarily before the resin being loaded to dryer or IMMs for product production.



Blank SUS Plastic Resin Silo Storage Bin Tank For Granules Storing OST-80 1



In the above cases, the storage tank is of optical model with capacity of 80L, it has an optical filter at the top of the cover and beside the suction box. This design can prevent 99% of the dust from entering into the plastic resin in the storage tank and pollute it. The optical grade storage tank is suggested for food-grade or optical-grade plastic parts production.
